U-MOUNT Fork for Binoculars 150mm

Sky Rover launched U-MOUNT in 2019; it is suitable for giant binoculars. The tripod is made of aluminium and stainless steel. Each axis is with bearings to ensure rotating accuracy, the disk provide damp, and the side handles provide locking. The base hole is a 3/8 screw, which is designed to fit on most of tripod. It is with a quick-release plate to make it easy to install, a rational design allows you to use your binoculars at multiple angles.

Specifications

Material: Aluminium + Stainless Steel

Base hole: 3/8 Screw

Net Weight: 13kg

Dimension: 580x500x260mm

Structure

U-MOUNT for 150ED BINO (Compatible with WIDE LOSMANDY PLATE)

• (1) Altitude Tension Knob
• (2) Quick Release Clamp
• (3) Altitude Tension Knob
• (4) Handle
• (5) Bumper Tape
• (6) Support Shaft
• (7) Lubrication Cover
• (8) Horizontal Tension Knob
• (9) Horizontal base
• (10) 3/8 screw

Installation

1. Install the horizontal base to your tripod, and put the lubricant cover in the correct position.

2. Insert the U-MOUNT head into the base.

3. Mount the binoculars and adjust the balance and tension.
